Chipset
|
AMD A320
|
|
CPU Support
|
Socket AM4 supports AMD A-series APU, Ryzen APU / Ryzen CPU
|
|
Memory
|
Supports Dual Channel DDR4 1866/2133/2400/2667/2933
2 x DDR4 DIMM Memory Slot, Max. Supports up to 32 GB Memory
Each DIMM supports non-ECC 8/16 GB DDR4 module
* DDR4 - 2933 memory type only support for Ryzen 2 CPU.
* Please refer to www.biostar.com.tw for a Memory support list.
|
|
Integrated Video
|
By CPU model
Supports DX12
Supports HDCP
|
|
Storage
|
4 x SATA III Connectors (6Gb/s)
Supports AHCI & RAID 0, 1, 10
|
|
LAN
|
Realtek RTL8111H
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
|
|
Audio CODEC
|
7.1 Channels, High Definition Audio
USB 4 x USB 3.2 (Gen1) ports (2 on rear I/Os and 2 via internal headers)
8 x USB 2.0 ports (4 on rear I/Os and 4 via internal headers)
|
|
Expansion slot
|
2 x PCIe 2.0 x1 Slot
1 x PCIe 3.0 x16 Slot (The bandwidth is depended on CPU)
|
|
Rear I/O
|
x PS/2 Keyboard/ Mouse
1 x VGA Port
1 x HDMI Port
1 x LAN port
2 x USB 3.2 (Gen1) Ports
4 x USB 2.0 Ports
3 x Audio Jack
|
|
Internal I/O
|
4 x SATA III 6.0Gb/s Connectors
2 x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)
1 x 4-Pin Power Connector
1 x 24-Pin Power Connector
1 x CPU Fan Connector
1 x System Fan Connector
1 x Front Panel Header
1 x Front Audio Header
1 x Clear CMOS Header
1 x COM Serial Header
|
|
H/W Monitoring
|
CPU / System Temperature Monitoring
CPU / System Fan Monitoring
Smart / Manual CPU Fan Control
System Voltage Monitoring
|
|
Dimension
|
Micro ATX Form Factor Dimension: 17.4cm x 22.6cm ( W x L )
|
|
OS Support
|
Supports Windows 7(64 bit) / 10(64 bit) / 11(64 bit)
|
|
Bundle Software
|
BullGuard
|
|
Accessories
|
2 x SATA Cable
1 x I/O Shield
1 x DVD Driver
1 x Quick Guide
|
|
Features
|
Supports 100% Solid capacitor
BIO-FLASHER
Supports BIOS Online Update
|
