Colorful Intel CVN Z590M Gaming Frozen V20 Gaming Motherboard

Colorful Intel CVN Z590M Gaming Frozen V20 Motherboard | Supports Intel 10/11 Gen Core Processors | Supports 4* DIMM DDR4 Slots, SATA 3.0, PCIe 4.0 | HDMI & USB 3.2 Gen 2 Ports | WiFi 6

Spin UpSpin Down
  • Intel CVN Z590M V20
  • Colorful - Gaming Motherboard
  •  Delivery within 48hour
  •  COD, Bank Transfer
Product Description

  • PCIe 4.0: Widely used standard for input/output connectivity in computers. Operates at a signaling rate of 16(GT/s) per lane, effectively doubling the interconnect performance bandwidth compared to the previous version, PCIe 3.0.
  • Compatible CPU: Supports 10th Gen and 11th Gen Intel core processors.
  • USB 3.2 GEN 2 Type C: Allows users to transfer files faster.
  • SATA III 6Gbps: SATA III 6Gbps is 2 times faster than SATA II. It provides a higher bandwidth to retrieve and transfer HD media.
  • HD Audio: The motherboard provides 6-channel high-resolution audio with minimal loss of audio accuracy.
  • LED Header: Provided 2*5v 3-pin RGB headers & 2*12v 4-pin RGB headers.
  • Video: With the help of the new HDMI 4k2k provides high-definition videos with richer scenes.
  • WiFi 6 & 6 E Module: Enables integration with compatible WiFi 6/6E modules for high-speed, low-latency wireless connectivity, offering advanced performance and broader bandwidth for modern networking needs.


Cpu Support

10th Gen and 11th Gen Intel® Core Processors

Memory Slots

4 Slots

Input Output and Extension Support

6*USB2.0 (2 rear,2 header)

2*USB3.2 Gen2(1*Type-A+1*Type-C)

6*USB3.2 Gen1 ports(4 rear,2 header)

Supports English Storage and RAM

4* DIMM ,Support DDR4 3200/2933 (OC support)

*memory overclocking also depends on the matching CPU and memory itself!

6*SATA3.0 ports

2*M.2 slots

*silk-screen"M2_KEYM2": Support  PCIE Gen4 x4 SSD

(Supported by 11th Generation processors only)

*silk-screen"M2_KEYM1": support PCIE Gen3 x4/SATA/Optane

*all support 2242/2260/2280 size SSD


integrated 1000M LAN

Visual Port

DP+HDMI ports

LED Headers

2*5V 3-pin RGB headers,2*12V 4-pin RGB headers
